Medium Speed Smart Paper Cup Machine Upgrade Strengthen Bottom Heating

The Medium Speed Smart Paper Cup Machine Upgrade with Enhanced Bottom Heating produces beverage paper cups, tea paper cups, coffee paper cups, advertising paper cups, and market paper cups through a fully automated process that includes automatic feeding of printed fan paper, sealing, oil application (for lip lubrication), punching the bottom (automatically blanking the cup bottom from the continuous paper roll), heating, crimping (for cup bottom sealing), and edge rolling.

Yongbo Machinery Medium Speed Smart Paper Cup Machine Upgrade Strengthen Bottom Heating YB-S100 Basic information



Model number	YB-S100	brand	YongBomachinery
speed	100-110min/pcs	country	China
trademark	Customized	After sale	Online
transport	Wooden Case	warranty	1year(non-human reason)



Yongbo Machinery Medium Speed Smart Paper Cup Machine Upgrade Strengthen Bottom Heating YB-S100Machine data

Model number	Medium speed smart paper Cup Machine Upgrade (strengthen bottom heating)YB-S100
Paper cup size	2-12oz (Mold replaceable, Max cup height: 115mm, Max bottom width: 75mm)
Operating speed	100-110 PCS/min (speed is affected by cup size, paper quality thickness)
Raw material	Single or double sided PE coated paper (suitable for hot and cold drink cups)
Gram weight of paper	150-350 grams per square meter
voltage	50/60HZ,380V/220V
Total power	5 kw
Gross weight	2500 kg
Machine size (length * width * height	2200*1350*1900mm (machine size) 900*700*2100mm (Cup receiver size)
Cup body bonding mode	Ultrasonic wave



Yongbo Machinery Medium Speed Smart Paper Cup Machine Upgrade Strengthen Bottom Heating YB-S100 Flat display

Yongbo Machinery Medium Speed Smart Paper Cup Machine Upgrade Strengthen Bottom Heating YB-S100 Product introduction



Medium Speed Smart Paper Cup Machine Upgrade Strengthen Bottom Heating YB-S100 it is a multi-station automatic forming machine. Medium Speed Smart Paper Cup Machine Upgrade Strengthen Bottom Heating produces beverage paper cup, tea paper cup, coffee paper cup, advertising paper cup and market paper through automatic feeding (printed fan paper), sealing, oil filling (winding mouth lubrication), punching bottom (automatically blanking cup bottom from web paper), heating, knurling (cup bottom sealing), edge rolling and cup unloading collection and other continuous processes, as well as photoelectric detection, fault alarm, counting and other functions Ideal device for cups, ice cream paper cups or other disposable food paper containers.

(Note: The actual production capacity of the machine is affected by many factors. The above data is for reference only.)

Paper feed	Bottom cover and crimped edges
CAM drive system	Bottom feed system

Production display
